Bostitch F21PL - Page 2

?N89RH17-1
A 500 B 355 C 133 D 3.6 E 91 F 99.8
G 86.8 H 3.51 I 8.27 J 4.83 K 2.47 L 6
M BC602 N BC603 O
MAGNALUBE P RH17 Q(a) RH= 2.8-3.3 Q(b) RH= 50-90
R RH=6.7-7 S 50-75 T 161 U N/A
?N89RH-2MCN
A 500 B 355 C 133 D 3.6 E 91 F 99.8
G 86.8 H 3.51 I 8.27 J 4.83 K 2.47 L 2
M BC602 N BC603 O
MAGNALUBE P MCN/RH17 Q(a) MCN=2.8-4.1 Q(b) RH17 = 2.8-3.3
R MCN=8/RH=7 S 25-75 T 161 U N/A
?F21PL-E
A 517 B 355 C 133 D 3.7 E 95.7 F 100.1
G 87.1 H 3.31 I 8.27 J 4.83 K 2.47 L 2
M BC602 N BC603 O
MAGNALUBE P MCN/RH Q(a) MCN= 2.8-4.1/RH= 2.5-3.3 Q(b) MCN = 38-64/RH= 45-90
R MCN=8/RH=6.7-7 S 25-75 T - U N/A
?F28WW-E
A 508 B 355 C 133 D 3.5 E 95.3 F 100.1
G 87.1 H 3.61 I 8.27 J 4.83 K 2.47 L 2
M BC602 N BC603 O
MAGNALUBE P WW/S Q(a) WW/S= 2.8-3.3 Q(b) WW/S= 50-90
R WW/S= 7.5 S 75-90 T - U N/A
?F33PT-E
A 457 B 355 C 133 D 3.6 E 83.9 F 90.7
G 77.7 H 3.62 I 8.27 J 4.83 K 2.47 L 2
M BC602 N BC603 O
MAGNALUBE PPT Q(a) PT=2.5-3.3 Q(b) PT= 50-90
R PT=7.2 S 38-75 T - U N/A
Q(a)
Q(b)
?F33PTSM-E
A 360 B 355 C 133 D 3.5 E 90.8 F 99.7
G 86.7 H 3.026 I 8.27 J 4.83 K 2.47 L 2
M BC602 N BC603 O
MAGNALUBE PPT Q(a) PT=2.5-3.3 Q(b) PT= 50-90
R PT=7.2 S 38-50 T - U N/A
