All screws and nuts are metric.
FASTENER SPECIFICATIONS:
5D to 70D Bulk Nails.
TOOL AIR FITTING:
This tool uses a 1/4" N.P.T. male plug. The inside diameter should be .200” (5mm) or
larger. The fitting must be capable of discharging tool air pressure when disconnected
from the air supply.
OPERATING PRESSURE:
80 to 125 p.s.i.g. (4.9 to 8.8 kg/cm
2
). Select the operating pressure within this range for
best fastener performance. DO NOT EXCEED THIS RECOMMENDED OPERATING
PRESSURE.
AIR CONSUMPTION:
Model PN100 requires 2-4 cubic feet per minute.
-4-
PN100 TOOL SPECIFICATIONS
MODEL LENGTH HEIGHT WIDTH WEIGHT
PN100 4.12" (105mm) 5.25" (133mm) 3.50" (89mm) 2.9 lbs. (1.31kg)
