User Manual DR-512
1 General Instruction
DR-512 is a professional DMX recorder with many useful functions. This unit can
translate standard DMX512 signals into recorded data, and send them out at any convenient
moment. These signals can be recorded to both the internal storage and the external CF card.
For internal storage, there are six sequences to be used availably : sequences
I01~I04,
STARTUP and SHUTDOWN. And for CF card, there are 33 different sequences (E01-E33)
available. This product offers SMPTE trigger function. There are 6 different modes usable :
MANUAL, AUTOSTART, DMX MON, DMX TRIGGER, PROGRAM and SETUP .
2 Features
• Professional DMX recorder, access to memory and CF card.
•
4 sequences (I01-I04) + Startup + Shutdown, available in memory.
•
33 sequences (E01-E33) available in CF card.
•
Capable of PLAY, PAUSE and STOP functions.
•
Manual / Autostart / DMX monitor / DMX trigger / Program / Setup mode.
•
24 / 25 / 30 frames SMPTE signal available.
•
Exclusive 32 MB CF card is recommended and can be provided at user’s request.
•
DMX 3Pin input/output, SMPTE 3Pin input/output, 9Pin connector.
•
Line remote control recalls PLAY, STOP and RECORD functions.
•
2×16 characters LCD screen.
3 Notice Information
3.1 Warnings
• keep the unit dry, do not expose it to water or high levels of humid.
•
Do not try to dismantle or modify the product.
•
Turn off the power if not using this unit for a long time.
•
Any strong shocks or vibration may result in malfunction.
•
This unit must operated by adults, do not allow children to play with it.
3.2 Copyright :
No part of this product can be reproduced, transmitted, or translated into any language
in any form without authorized permission.
3
