User Manual DR-512

5 LCD Display

I01 MANUAL ■

Sh01 00:00:00

• Press “PLAY” , “►” will appear on the top right corner of the LCD;

Press “PAUSE”, “

ll” will appear on the top right corner of the LCD;

Press “STOP”, and “■” will appear on the top right corner of the LCD.

• The characters in the middle of the first line on the LCD stand for the MANUAL,

AUTOSTART, DMX MON, DMX TRIGGER, PRG MODE or SETUP mode.

• In the first display line , “

I” means “internal”, while “E” means “external” , and the

following “01~33” means one of the sequence numbers.

• In the second display line, “

Sh01” means one of the Sequence names. It can be

amended by using the “Enter” key under PROGRAM mode only. But on the other

hand, the StUp(START UP) and StDN(SHUTDOWN) can not be amended.

• The time displays on the bottom right corner of the LCD. When it shows like “××:×

×:××” (Hour, Minute, Second), that means the time of internal storage. While

shows like “××:××:××:××” (Hour, Minute, Second, Frame), that just means the

SMPTE time. The time-display pattern can be switched through “Sys Time” item

under SETUP mode.

6 Operation modes

6.1 MANUAL mode

• This mode has the most freedom to operate upon this unit. The user can select any

one of the sequences at any time to run, pause or stop the current sequence. And

further more,

the operating upon STARTUP and SHUTDOWN are also available.

• For internal storage, select one of the

I01-I04 sequences and press the PLAY key to

run the sequence. This sequence will run circularly unless you press the PAUSE or

STOP key.

• For internal storage, press the STARTUP key, then the STARTUP sequence will

circulate once, and other sequences will run subsequently.

• Still for internal storage, press the SHUTDOWN key, then the SHUTDOWN

sequence will circulate for one time, and other sequences will be stopped.

dimensions	482×120×44mm
weight	1.6 kg
