BougeRV BJ4880F - Technical Parameters; Product Dimension

22
Product Dimension: 260*200*93mm
Installation Area Dimension: 192*184mm
Installation Hole Size:  5mm& 10mm
Connection Socket Size: 10*10mm
BJ4880F/BJ48100F Model
19. Product Dimension
Accessory List
External Temperature Sensor
External LCD Display Screen
Inbuilt Bluetooth
Installation Guide Board
User Manual
Package Status
Yes
No
Yes
184mm
200mm
192mm
260mm
93mm
No
18. Technical Parameters
Model No.
Battery System Voltage
No-load Loss
Max Solar Input Voltage
Rated Solar Charge Current
Max Solar Input Power
Storage Temperature
IP Protection
Net Weight
Communication Port
Controller Dimension(mm)
BJ4880F
12V/24V/36V/48V
Auto (FLD/GEL/SEL/USE)
Manual (LI/USE)
80A
-40ºC ~ +80ºC
IP32
RS485(RJ12) + BT
≤ 3000 meters
Parameter
Battery Parameters
Battery Types
Equalize Charge Voltage
Boost Charge Voltage
Float Charge Voltage
Boost Charge Recovery Voltage
Over-discharge Recovery Voltage
Over-discharge Voltage
AutoTemperature Compensation
FLD SEL GEL(default)
14.8V*n 14.6V*n --
14.6V*n 14.4V*n 14.2V*n
13.8V*n
13.2V*n
-3mV/2V/ºC
USE(adjustable)
Default: GEL
Default: GEL
Default: GEL
Default: GEL
LI (adjustable)
--
Default: 14.2V*n
--
--
--
--
BJ48100F
<150Voc
100A
2.5 kg
260*200*93
2.5 kg
12ma(12V), 10ma(24V), 8ma(36V), 6ma(48V)
System Wiring Grounded
Negative Grounded
Parameter Value
1200W/12V; 2400W/24V
3600W/36V
;
4800W/48V
1500W/12V; 3000W/24V
4500W/36V
;
6000W/48V
Operating Temperature
-25ºC ~ +45ºC
Support Parallel
Support parallel (up to 9 units)
Operating Altitude
--
--
--
-- --
--
The variable “n” is adopted as a multiplying factor when calculating parameter voltages, the rule for “n” is listed
as: if battery system voltage is 12V, n=1; 24V, n=2; 36V, n=3; 48V, n=4.
For example, the equalize charge voltage for a 12V FLD (Flooded) battery bank is 14.8V*1=14.8V. The equalizing
charge voltage for a 24V FLD (Flooded) battery bank is 14.8V*2=29.6V.
Fan-onTemperature
> 45ºC
23
93mm
Yes
