Bowa ARC PLUS - Symbols on the Device

3 Description
900-001_IFU_V1.0_11270-S0-20130118-EN ARC PLUS Operating Manual 21
3.2. Symbols on the device
Symbol
Designation
Purge button
Fault indicator
Gas status indicator
Connector for gas bottle 1
Connector for gas bottle 2
Connector for electronic pressure sensor
Bleed stub for pressure reducer
Fibre optic signal output
Fibre optic signal input
Equipotential bonding
Fuse
Alternating current
HF energy in the range of 9 kHz to 400 GHz is used
when the HF device is activated. This energy
generates electromagnetic radiation.
Labelling of electrical and electronic devices in
accordance with Directive 2002/96/EC (WEEE); see
"Disposal"
Manufacturer
Date of manufacture
Observe operating instructions
UART Serial communication port
