Bowa SHE SHA - Technical System Specifications

16 BOWA SHE SHA smoke evacuation unit MN009-940-S0 EN
2.4 Technical data SHE SHA Smoke Evacuation System
Performance
Model Number
950-001
Maximum Flow Setting (CFM-U.S.)
Standard Hose I.D.
22 mm (7/8’’) - 708 LPM (25 CFM)
9.5 mm (3/8’’) - 130 LPM (4.5 CFM)
6.4 mm (1/4’’) - 57 LPM (2 CFM)
Dimensions (H x W x D )
152 mm x 279 mm x 394 mm (6’’ x 11’’ x 15.5‘’)
Weight
4.4 kg (5.5 kg incl. filter)
Noise Level, dBA
max. 55.0 dBA
Foot switch Pneumatic
Standard
Remote Control Activation
YES
Safety Features
UL Classified
CE Marked
Fuse protection
Display
LED
Filter Status
Flow Rate
Service Required
Voltage Available
220/240 VAC
Frequency, auto sensed
50/60 Hz
Variable Flow Control
Yes
Motor
1000 W
±
10%
Motor Static Suction
25.69 kPa (6.5 mm orifice)
