37
P12-P15-P18
6 Fixing the Machine in Place 6
Adhesive plugs/shear connector
Steps:
Position the machine in its intended position.
Use the holes of the angle bracket as a drilling template.
Pre-drill with a 14 mm (.5 in) stone drill. Drill in vertically!
Bore holes: Drill the diameter and depth according the information provided by the
plug manufacturer and blow out any dust.
For further steps, refer to the information provided by the plug manufacturer.
Note the hardening time.
Position the machine or attach the angle bracket and level.
If the floor is uneven, level the machine with wedges and even out the surface with filler (epoxy resins).
Tighten the nuts evenly.
