BÖWE P26 - Page 25

18
P21/P26/P30
5. Settings and Optimum Operating Values 5.
Machine P21 P26 P30
Refrigeration technology:
Filling capacity, cooling agent R 404A kg
(lb)
4,6
(10.14)
4,6
(1
0,14)
4,6
(10,14)
Expansion valve:
Nozzle size: solvent cooling No. 03 03 03
Drying /reduction No. 01 01 01
High pressure control ON bar
(psi)
21
(304.6)
21
(304.6)
21
(304.6)
High pressure control OFF bar
(psi)
25
(362.6)
25
(362.6)
25
(362.6)
Low pressure control bar
(psi)
2
(29)
2
(29)
2
(29)
Drying:
Cooling water regulator setting:
Adjust 4 – 6 min. after start of drying bar
(psi)
18
(261.1)
18
(261.1)
18
(261.1)
Temp. sensor, cage inlet °C
(°F)
60
(102)
60
(102)
60
(102)
Temp. sensor after cooler:
Control value, drying °C
(°F)
40
(104)
40
(104)
40
(104)
Control value, cycle end °C
(°F)
15
(59)
15
(59)
15
(59)
Distillation:
Cooling water regulator condenser °C
(°F)
45
(113)
45
(113)
45
(113)
Thermal sensor:
Cycle distillation OFF °C
(°F)
135
(275)
135
(275)
135
(275)
Still stripping OFF °C
(°F)
138
(280)
138
(280)
138
(280)
Thermal sensor, distilled solvent °C
(°F)
55
(131)
55
(131)
55
(131)
Restrictor in steam feeder mm
(in)
6
(0.24)
6
(0.24)
6
(0.24)
Restrictor in direct steam line mm
(in)
4
(0.16)
4
(0.16)
4
(0.16)
* Option
