Bowflex BXE326 - Hardware; Tools

Assembly / Owner’s Manual
9
Hardware
Item Qty Description Item Qty Description
A 29 Button Head Screw, M8x1.25x16 G 6 Pan Phillips Screw M3.9x16
B 31 Lock Washer, M8 H 8 Flat Washer, M8x24 Large
C 18 Flat Washer, M8x18 I 6 Wave Washer, M8
D 2 Lock Nut, M8 J 9 Curved Washer, M8
E 2 Button Head Screw, M8x1.25x25 K 2 Socket Head Cap Screw, M8x16
F 4 Pan Phillips Screw M3.9x38 L 2 Pivot Pin
Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may be remaining Hardware
after the proper assembly of your machine.
Hardware / Tools
A B C D E F
G H
I
J
K L
Tools
Included Not Included
6mm - short
6mm - long
(recommended)
#2
13mm
15mm
19mm
