6. Carefully pivot the Console Display from the Console Assembly.
7. Pivot the new Console Display into the Console Assembly.
8. Installation is the reverse procedure.
9. Final Inspection
Inspect your machine to ensure that all hardware is tight and compo-
nents are properly assembled.
Do not use until the machine has been fully assembled
and inspected for correct performance in accordance
with the Owner’s Manual.
Console Display
Console Assembly
