User’s Manual
14
13. Attach the Rear Shroud to the Frame Assembly
NOTICE: Place the inside hook of the Rear Shroud on the Frame Assembly and then pivot it up into place.
#2
X1
D
14. Dispose of all remaining parts according to your local regulations.
15. Final Inspection
Inspect your machine to ensure that all hardware is tight and components are properly assembled.
Note: Remove any protective covers from the face of the Console.
Do not use until the machine has been fully assembled and inspected for correct performance in accordance with the Owner’s
Manual.
