User’s Manual
16
A Console I Rail Assembly
B Media Shelf J Roller
C Media Capture Bar K Pedal
D Aerobars L Water Bottle Holder / Tray
E Resistance Fan M Contact Heart Rate (CHR) Sensors
F Power Connector N Static Handlebars
G Transport Roller O Dynamic Handlebars
H Leveler P Bluetooth
®
Connectivity (not shown)
Use the values calculated or measured by the machine’s computer for reference purposes only. The heart rate
displayed is an approximation and should be used for reference only. Over exercising may result in serious injury or
death. If you feel faint stop exercising immediately.
Features
F
E
G
H
H
I
K
C
A
N
O
L
J
M
D
B
