48
Note: Your machine may not match the images provided exactly.
1. Unplug the AC Adapter from the wall outlet and machine.
2. Using a 4mm hex wrench, remove the hardware
(indicated by ovals) from the Media Rack.
3. Slide the Media Rack from the Handlebar Assembly.
4. Remove the Console Cable from the Console.
NOTICE: Do not cut or pinch the cable.
5. Push the Console Securing Tab in and push the
Console upward. The Console will slide up and o
of the Handlebar Assembly.
Media
Rack
Console
Console
Cable
Console
Securing
Tab
To Next Page
