Cable Connector
Tab
Left
Structural
Shroud
Main Mast
Cable
Grommet
16. Re-install all remaining parts that were removed in
reverse order.
Slide the Grommet down into the opening between
the Structural Shrouds.
Note: Do not cut or pinch the Console Cable.
When re-connecting the Cable to the Console,
the Cable Connector has a tab that can only be
connected to the Console in one orientation. Connect
the Console Cable to the Console in the proper
orientation.
NOTICE: Do not cut or pinch the cable.
To Next Page
