Bowflex Power Pro - Lat Pulldown Attachment Assembly Instructions

Lat Pulldown Attachment
Assembly Instructions
Box Contents
1 Cross Bar
1 Main Frame Lower Half
1 Upper Main Frame
2 Main Frame Brackets
1 T-Piece with pulley, and Rest Brackets
2 59" Cables
1 48" Long Bar
1 Parts/Bolt Bag
Name: Plastic Bumper
Part #: 98202
Quantity: 1
Name: 1/4" Nylon Lock Nut
Part #: 90204
Quantity: 2
Name: 1/4" Wing Nut
Part #: 90265
Quantity: 2
Name: 3/8" Nylon Lock Nut
Part #: 90196
Quantity: 2
Name: 1/4" x 7"
Carriage Bolt
Part #: 90227
Quantity: 2
Name: 3/8" x 3 1/2"
Hex Head Bolt
Part #: 90278
Quantity: 2
Name: 1/4" x 3 1/2"
Hex Head Bolt
Part #: 90127
Quantity: 2
Name: Snap Hook
Part #: 50334
Quantity: 2
18
The Lat Pulldown Attachment is an optional
attachment. Depending on the machine
and accessories you ordered, this
attachment may or may not be included.
Name: #10 Screw
Part #: 90208
Quantity: 2
Components for this assembly
are in a box labeled
Lat Pulldown Attachment
