Step 2.
Note: Set the hardware safely aside for reassembly.
Discard the base plates (a).
Use proper safety precautions and lifting
techniques. Bend your knees and elbows, keep
your back straight and pull up equally with both
arms. Straighten your legs to lift.
Item Qty Description
6 2 Gusset
7 1 Media Rack
Step 3.
Note: Attach the Uprights to the Base with the hardware that
was removed in Step 2.
7
X8
6mm
X2
D
E
3mm
6
X4
3mm
E
D
6
6mm
a
a
Assembly / Owner’s Manual
4
