Assembly / Owner’s Manual
10
Hardware / Tools / Assembly
Item Qty Description Item Qty Description
A 32 Socket Hex Head Screw, M8x1.25x16 Black D 4 Pan Phillips Head Screw, M4x10 Black
B 34 Flat Washer, M8x18 Black E 8 Pan Phillips Head Screw, M4.2x13 Black
C 34 Lock Washer, M8x14.8 Black F 2 Socket Hex Head Screw, M8x1.25x12 Black
Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may be remaining Hardware
after the proper assembly of your machine.
6mm #2
Tools
Included
DO NOT CUT the Shipping Strap on the Base Assembly until it has been placed face up as shown in the
appropriate work space.
*
When moving the Deck Assembly, be sure to grasp the sides of it. Do not grasp the Walking Deck Release
Button. Pressing the Walking Deck Release Button releases the locking mechanism on the hydraulic lift.
Hardware
A
B
C
D
E
F
To Next Page
