Bowflex Xtreme
®
SE Assembly Manual
Parts Reference Guide
ITEM QTY. DESCRIPTION
1 4 FOOT, END CAP, FRAME
2 1 BASE FRAME
3 1 RIGHT FRAME RAIL (Cable Pulley Slider and
Cable are included with frame rail pulley)
4 1 LEFT FRAME RAIL (Cable Pulley Slider and
Cable are included with frame rail pulley)
5 1 REAR CROSSMEMBER
6 1 ABDOMINAL BRACKET
7 1 LAT CROSS BAR W/ PULLEYS (One cable is
wrapped in each pulley bundle)
8 1 UPPER LAT TOWER
9 1 RIGHT PULLEY ARM
10 1 LEFT PULLEY ARM
11 1 LOWER LAT TOWER FRAME
12 1 SQUAT PULLEY FRAME
13 1 SEAT BACKBONE
14 1 SEAT SUPPORT RAIL
15 4 PULLEY SLIDER
16 20 BUTTON HEAD CAP SCREW
0375-16X0.75 G2
17 1 BUTTON HEAD CAP SCREW
0375-16X5 G2
18 2 BUTTON HEAD CAP SCREW
0375-16X3 G2
19 2 BUTTON HEAD CAP SCREW
03125-18X2.5 G2
20 4 BUTTON HEAD CAP SCREW
03125-18X0.75 G2
21 3 FLAT WASHER 0250
22 6 FLAT WASHER 0313
23 32 FLAT WASHER 0375
24 4 FLAT WASHER 0500
25 3 PHILLIPS SCREW 10-24X1
ITEM QTY. DESCRIPTION
26 2 THREADED STUD 0.500-13X9.5X.625X.750 BLK
27 5 LOCK NUT 0375-16 G2
28 4 LOCK NUT 0500-13 G2
29 1 LOCK KNOB
30 2 BUTTON HEAD CAP SCREW
.375-16X1
31 2 BUTTON HEAD CAP SCREW
.0375-16X2.75 G2-BlkO
32 Not used
33 1 BRKT, AB CRUNCH
34 1 XTREME SE AB BRKT TUBE ASSY
35 2 CHROME TUBE, FOAM ROLLER
36 4 FOAM ROLLER
37 4 END CAP, 3/4 INCH
38 1 PIN, LEG EXT
39 1 LEG EXTENSION BACKBONE ASSEMBLY
40 1 XTREME SE SEAT ASSEMBLY
41 1 XTREME SE SEAT BACK ASSEMBLY
42 1 BOWFLEX ROD PACK 210#
43 1 BAR 50” BENT LAT BAR
44 1 BAR 48” LONG WITH FOAM GRIPS
45 1 ACC BAG LEG #1 ASSEMBLY
46 1 PVC HANDGRIP PAIR ASSEMBLY
47 1 AB CRUNCH STRAP ASSEMBLY
Tools included:
• 3/16” Allen Wrench
• 7/32” Allen Wrench
NOTE: Specifications Subject to Change Without Notice
