Bowflex Xtreme SE - Tools You will Need; Hardware Guide

Bowflex Xtreme
®
SE Assembly Manual
5
Hardware Guide
Button Head Screws:
Flat Washers:
Nylock Nuts:
Tools you will need:
You will need the tools listed below to complete the assembly of your Bowflex Xtreme
®
SE home gym. If
you don’t have these tools, you can find them at any hardware or department store.
• Flat Blade Screw Driver
• Rubber Mallet
• Utility Knife
• Scissors
• 7/16" Combination Wrench
• 9/16" Combination Wrench
• Adjustable Wrench
• Socket Wrench Set
• Phillips Screw Driver
Qty:2
(5/16
" x 2 1/2")
Qty: 2
(3/8" x 3")
Qty: 2
(3/8" x 1")
Qty: 4
(5/16
" x 3/4")
Qty: 20
(3/8
" x 3/4")
Qty: 2 Threaded Studs
(1/2" x 9 1/2")
Qty: 1
(3/8
" x 5")
Qty: 4
(1/2
")
Qty: 5
(3/8
")
Qty: 3
Self Threading Screws (#10 x 1
")
Qty: 32
(3/8
")
Qty: 6
(5/16
")
Qty: 3
(1/4
")
Qty: 4
(1/2
")
(NOTE: Drawings not to scale.)
Self Threading Screw:
Qty: 2
(3/8
" x 2 3/4")
