Braeburn 1025NC User Manual

5
NOTES - Conventional Systems
[1]Fora2-wirezonevalveyouwillnotconnectV3
[2]Ifbatteriesareinstalled,the24VoltACcommonconnectionisoptional
[3]Ifneededforsystem
Provide disconnect and overload protection as required.
3 Wire Hydronic Zone Valve
R PowerConnection
W1 ZoneValvePowerOpen
V3 ZoneValvePowerClose[note 1]
G FanControl [note 3]
C 24VoltACTransformerCommon[note 2]
Typical Wiring Configurations
Conventional Systems (cont.)
