OPA-100 INSTALLATION AND SERVICE OPERATIONS
MS0100-06-0_service_manual.doc 6/22 INSTALLATION AND SERVICE OPERATIONS
3 INSTALLATION AND SERVICE OPERATIONS
3.1 VERIFY COMPONENTS
Verify the availability of the components to install in your system:
3.1.1 SYSTEM N. 1 : PC+AGS-200+OPA-100
CODE DESCRIPTION Qt.
SW-800
OMNIBUS-800 software 1
AGS-200
Exhaust gas module 1
OPA-100
Smokemeter module 1
PSI-50
Power supplìer 1
MGT-300/R (*)
RPM Counter radio transmission 1
IF-030
PC connection cable 1
OMNI-020
Connection cable PSI/AGS/OMNIBUS (4 m.) 1
CMNI-010
Connection cable PSI/AGS/OMNIBUS (0.4 m.) 1
TRO-030
AGS/OPA trolley 1
TRO-020
Roll-stand for PC 1
(*) alternative : MG-7000 + MG-7011 (modulo radio-radio module)
In case MGT-300/R is not required, replace the code with following items :
ST-020
Temperature probe AGS/OPA (6 m.) 2
CPI-020
RPM Inductive clamp 1
RPM-020
Diesel RPM cable for piezo transducer (6 m.) 1
TSD-010
Piezo transducer diesel RPM reading for OPA-100 (d.6
mm)
1
DMO-810
Oscilloscope kit for PC with cables 1
OSCILLOSCOPE FUNCTION :
