OPA-100 TECHNICAL DOCUMENTS

MS0100-06-0_service_manual.doc 14/22 TECHNICAL DOCUMENTS

4.2 INTERNAL CABLES

4.2.1 Cables View

In the photo you can see:

1. Cable 1240100017XX ( omniBUS);

2. Cable 1240100016XX ( RS-232 );

3. Cable 1240100008XX ( RPM );

4. Cable 1240100015XX ( temp/prog).

Heating Resistor connections

(about 3,3 ohm each)

Electro valve coil connections (unpolarized

wires)

4 3 2 1
