< How to fold down the ROPS >
(1) Pull the pins to separate both sides.
(2) Raise the ROPS a little.
(3) Replace the pin.
(4) Fold down the ROPS, and the pins will lock into
place.
*If it is not certain whether the pins are xed, shake the
frame a little bit to x the pins for sure.
< How to fold up ROPS >
(1) Pull the pins on both sides of the tractor and turn
them about 1/4 turns to release the lock of the ROPS.
(2) Raise the ROPS a little.
(3) Replace the pins.
(4) Stand the ROPS up, and the pins will lock into
place.
*If it is not certain whether the pins are xed, shake the
ROPS a little bit to x the pins for sure.
(5) Turn the handle to x the push plate and the
frame.
MAINTENANCE AFTER WORK
