152
SPECIFICATION
Model
2400 2800 2400h 2800h
Engine
Engine model
A1100N2 A1100T1 A1100N2 A1100T1
Type
Vertical, 4 Cycle, Water Cooled, Diesel
Combusion system
Swirl chamber
Aspiration
Naturally Turbocharged Naturally Turbocharged
Engine output HP [kw]
24 [17.6] 28 [20.6] 24 [17.6] 28 [20.6]
Engine RPM RPM
2600 ← ← ←
No of Cylinder
3 ← ← ←
Bore x Stroke In [mm]
3.07 x 3.23 [78 X 82]
← ← ←
Displacement cu.in [cc]
71.7 [1,175] ← ← ←
Type of air cleaner
Dry, Double Filter Elements
Fuel tank Capacity gal [L]
6.08 [23L] ← ← ←
Electronic Alternator Amps
12V-50A
Battery Volt
12V
Steering
Hydrostatic
Clutch
Dry, Single stage
