99
c) There are 2- holes in top link mounting bracket
Top link needs to be moved from (A) to (B) as followed.
• The Position ‘A’ allows the minimum pressure.
• The Position ‘B’ allows the maximum pressure.
OPERATIONS & WORK
d) Turn the A-lever clockwise to rise up lift links. On the
contrary, turn the A-lever counter clockwise to lower
down lift links.
After adjusting, turn down the lever for
locking.
CAUTION
00 OPERATORS MANUAL (040512).indd 99 4/12/2012 10:19:53 AM
