Chapter 4: Installation and Setup
Placement of Equipment
4 - 2 100-413-016 Rev. C
4.1 Placement of Equipment
Install the unit in an area away from radiators or heating vents.
A fan maintains safe operating temperatures in the power supply by circulating air
over the components. Therefore, place the power supply so that the air intake
located at the rear of the power supply is not blocked.
If the temperature within the unit becomes excessive, a thermal cutout switch will
disconnect the power and keep it disconnected until the ambient temperature cools
to a safe operating level. Although the unit will automatically be re-energized
when a safe operating temperature has been reached, it should be checked to
determine the reason for the initial cutout. Periodically, unplug the unit and clean
the air intake at the rear of the power supply to ensure that dust or dirt is not
restricting the flow of air.
4.2 Power Requirements
The Sonifier unit requires a single-phase, three wire, 117V or 200-245V 50/60 Hz
source. The 117V line cord is equipped with a NEMA 5-15P plug and requires a
NEMA 5-15R receptacle. The 200-245V line cord, for European units, is
equipped with a CEE 7/7 plug.
