Branson Sonifier 250 - Power Supply Rear Panel

Chapter 2: Introduction
Model 250/450 Sonifier Power Supply Rear
Panel
2 - 6 100-413-016 Rev. C
2.4 Model 250/450 Sonifier Power Supply Rear Panel
Figure 2.3 Power Supply Rear Panel
Table 2.2 Rear Panel Device and Function
Item Function
1) Power Cord
Connects the power supply to an electrical outlet.
2) Fuse (4 AMP) Overload Protection
3) RF Cable Connects the power supply to the converter.
1 2 3
