Branson Sonifier 250 - Horn and Micro Tip Amplitudes

Chapter 6: Operation
Horn and Micro Tip Amplitudes
6 - 8 100-413-016 Rev. C
6.3 Horn and Micro Tip Amplitudes
Table 6.2 Horn Amplitudes
* All measurements in Microns.
Part No. Description
Output Control
Setting
1 5 10 max
101-147-037 1/2” Dia. Tapped Stepped Disruptor 21.0*
.0008"
76.0*
.003"
145.0*
.0057"
101-147-042 1/2" Dia. Solid Catenoidal 21.0*
.0008"
74.0*
.0029"
145.0*
.0051"
101-147-041 1/2" Dia. Solid Exponential 10.0*
.0004"
34.0*
.0013"
65.0*
.0025"
101-147-039 3/8" Dia. Solid Stepped Disruptor 36.0*
.0014"
125.0*
.0049"
240.0*
.0094"
100-147-043 3/4" Dia. Solid Stepped Disruptor 9.5*
.0004"
33.0*
.0013"
63.0*
.0025"
101-147-035 3/4" Dia. Solid High Grain 19.0*
.007"
68.5*
.0027"
130.0*
.0051"
101-147-044 1.0" Dia. Solid Stepped 6.3*
.0002"
21.5*
.0008
40.5*
.0016
