250 - 450 Sonifier Chapter 5: Technical Specifications
User’s Manual Specifications
100-413-016 Rev. C 5 - 3
*Output control at maximum setting.
5.1.2 Mechanical Specifications
Minimum
Starting Power
Model 250, 120 Watts.*
Model 450, 300 Watts.*
Temperature
Operating: 41ºF (5ºC) 104ºF (40ºC)
Ambient Storage and Shipping: -20ºF (-29ºC) to
158ºF (70ºC)
Tuning
Factory set, no tuning necessary.
Table 5.2 Mechanical specifications
Converter
Weight: 4 lbs (1.8 kg) with horn
Dimensions: 7" L x 2 1/2" dia. (180 x 60 mm)
Horn
Tip Diameter: 1/8" - 1" (3.2 - 25mm) dia. depending on
process needs.
Power
Supply
Weight: 15 lbs (6.8 kg)
Table 5.1 Electrical specifications
