What the controls do
PROPRIETARY AND CONFIDENTIAL
THIS DRAWING CONTAINS INFORMATION WHICH IS THE PROPRIETARY
PROPERTY OF BALBOA WATER GROUP. REPRODUCTION IN WHOLE OR IN
PART WITHOUT EXPRESS WRITTEN PERMISSION IS PROHIBITED.
Overlay Graphics Template (VL240, ML240)
Use this to create overlay graphics only. Do not use this template to create a die cutting tool.
06
1
2 3
5 64 7
1
Temp Display 10°C is displayed as 100.
1°C is displayed as 10.
0.1°C is displayed as 01.
2
Temp down The lowest temp setting is 0°C displayed as 00.
3
Temp up
The highest temperature setting is 10°C. Note: the bath will not heat up, if you
toggle temp up it will stop cooling and the water will naturally get warmer.
4
Defrost mode
Press and hold the up arrow for 3 seconds to put the bath into a
defrost mode for 30 minutes - this will release any ice on the bottom
of the bath. Press and hold again to exit defrost mode.
5
Ice Boost
Use Ice Boost when the temperature is set below 0.5°C and the bath idle i.e. not
cooling - the bath will then perform 8 additional sheets over approximately 8 hours.
6
Maintenance Mode
Press and hold ICE BOOST for 3 seconds to put the bath into a maintenance
mode - The light in the bath will flash 3 seconds on 3 seconds o whilst in this mode.
From here you can change the filter, the UV bulb and empty the water. Don’t forget
to exit maintenance mode by pressing and holding ice boost for 3 seconds again.
7
User start mode
This will begin a session in the bath. It switches everything o for a peaceful
experience and ensures that any ice on the base of the bath is defrosted.
When the light in the bath is solid blue it is safe to get in the bath.
If the blue light in the bath is flashing it means a defrost cycle
is necessary. This will run for 7-8 minutes and will then revert
to solid blue meaning it is now safe to get in the bath.
10 Ice Bath Quickstart Guide 11Ice Bath Quickstart Guide
