Page 18
Pump Module Parts List
NL917IB-2 NL917FIB-2
Item Qty. Description NL919IB-2 NL919FIB-2
1 Pump Module (complete), 12 Volt, Rear 947-2516RNA 947-2516FNA
1 1 Pump Assembly (M268-0114) 12V-120G - Triple Relief (Includes Items 1 & 2) 32915-12V 32915-12V
2 1 Solenoid, Up - 4-Post - Trombetta (Flat Mount) 31374 31374
3 1 Housing, Pump
(Complete Assembly 947-0513RNA or 947-0513FNA Includes Items 3 - 16)
947-0513RN 947-0513FN
4 1 Beeper, Constant - High Output 33251 33251
5 1 Switch, Toggle w/ Gold Contacts 31787 31787
6 1 Stud, Power Feed 26084 26084
7 1 Lens, Threshold Warning - Red 30704 30704
8 1 Spacer, Lens - NHTSA 31386 31386
9 1 Metal Ring Base - Lamp 30971 30971
10 1 Socket, Lamp 30703 30703
11 3 Screw, #8-32 x 1/2" Pan Head Phillips - Thread Cut 30974 30974
12 1 Bulb, Light 19841 19841
13 2 Clamp, Spring - Pump Handle 12350 12350
14 4 Rivet, Pop, SD43BS - 1/8" - .13"/.19" 12954 12954
15 5 Rivet, Pop, SD64BS - 3/16" - .13"/.25" 11513 11513
16 1 Diode, Green LED 29545 29545
17 1 Cover, Pump Module 947-0519RN 947-0519FN
18 2 Fitting, Male 7/16-20 O-Ring to Male 7/16-20 JIC 37° 24504 24504
19 1 Elbow, Female Swivel 7/16-20 JIC 37° to (2) Male 7/16-20 JIC 37° 26579 26579
20 4 Rivet, Snap, .122" Dia. - .158" -.197" Thick 25759 25759
21 1 Washer, 5/16" External Tooth 16368 16368
22 2 Bolt, 5/16-18 x 3/4", Nylock, Hex * See note below 29608 29608
23 2 Bolt, 5/16-18 x 1/2", Nylock, Hex * See note below 10012 10012
24 2 Washer, 5/16" Flat 10063 10063
25 1 Pump Handle with Grip 17206A 17206A
26 1 Cycle Counter, LCD w/o Reset 30547 30547
27 1 Flasher, 12V 32461 32461
28 2 Relay, 30/40A SPDT 12V 18087 18087
29 3 Nut, #10-32 w/Lockwasher 18349 18349
30 1 Screw, #10-32 x 3/8", T-Head, Thumb 33435 33435
31 2 Rivet, Snap, .201" x .217"/.256" 25973 25973
32 1 Cable, Pump Module Power 26082A-4 26082A-4
33 1 Harness, Main w/Redundant Fuse 32934A 32934A
34 1 Harness, Ground Interlock 32864A 32864A
35 1 Cable, Lift / Chassis Ground 22166A 22166A
36 1 Harness, Threshold / Flasher 32886A 32886A
37 1 Harness, Fold Relay 32967A 32967A
38 1 Harness, Light Relay 33362A 33362A
39 1 Wire Assembly, Lift Interlock Connection 31797A 31797A
40 1 Wire Assembly, Lift Stowed Connection
tSee note below 31798A 31798A
41 1 Rubber Boot, Red
tSee note below 82046 82046
42 1 Control, Hand Pendant Assembly - Non Electronic / Non Shielded - Coiled
tSee note below 33659A 33659A
43 1 Diode Assembly, Up Solenoid 73906A 73906A
44 1 Harness, Lift Power
tSee note below 33688A 33688A
45 1 Harness, Tower / Opposite Pump (Not shown - see Wiring Diagram) 33231A 33231A
46 1 Harness, Bridge Inputs (Not shown - see Wiring Diagram) 33249A 33249A
47 1 Harness, IB Occupied / Stow (Not shown - see Wiring Diagram) 33257A 33257A
48 1 Harness, Cycle Counter (Not shown - see Wiring Diagram) 32885A 32885A
49 1 Harness, Tower / Pump Side (Not shown - see Wiring Diagram) 33255A 33255A
50 1 Harness, Extension Lighting - 54" (Not shown - see Wiring Diagram) 31033A54 31033A54
51 1 Harness, Extension Lighting - 99" (Not shown - see Wiring Diagram) 31033A99 31033A99
52 1 Harness, IB / OB / Bridge / Towers 1 & 2 (Not shown - see Wiring Diagram) 33615A 33615A
53 1 Hose Assembly, 86" - 1/8" Dia. - Swivel Ends (Not shown - see Hydraulic Diagram) 16004A-086 16004A-086
54 1 Hose Assembly, 46" - 1/8" Dia. - Swivel Ends (Not shown - see Hydraulic Diagram) 16004A-046 16004A-046
55 1 Hose Assembly, 3/16" Dia. w/Two Guards (Not shown - see Hydraulic Diagram) 915-2601-139 915F5604A-179
56 1 Hose, 1/8" Thermal Plastic (Not shown - see Hydraulic Diagram) 23742R 23742R
57 1 Decal, Warning / Pressure Relief Valve (Not shown)
tSee note below 22249 22249
58 1 Decal, Lift Power - On/Off (Not shown)
tSee note below 21494 21494
59 1 Decal, Fold & Barrier Relief Valve Adjustment (Not shown)
tSee note below 33233 33233
60 1 Decal, Manual Instructions - Public (Not shown)
tSee note below 32940 32940
* Apply red #271 Thread Locker Loctite
®
to the four hex bolts (items 22 and 23) if a blue nylon patch is not present on
the bolts when retrofitting an M268-0114 pump assembly. Loctite
®
is available from The Braun Corporation under part
number 11522-1.
t Indicates items available for replacement part purposes only. These items are not included with replacement pump
modules.
