Inboard
Outboard
Right
Left
Threshold Strip Switch
32600A (Qty. 2 per)
Ground Detect
Microswitch
33434A
Outer Barrier
Raised Microswitch
33434A
IB Occupied
Microswitch
Stow Interlock
Microswitch
IB Occupied & Stow Interlock Assy.
32514NA
IB Raised Switch
32519A
Bridging
Microswitch
32855A
*Up Microswitch
*Unfold Microswitch
*Threshold / Alarm
Microswitch
*Up & Unfold Microswitch Assy.
975-3121A
*Threshold / Alarm
& Partial Fold
Microswitch Assy.
975-3121A
*Partial Fold
Microswitch
*Note: Mirror image for
left (rear) pump lifts.
Switch and Sensor Locations
