Braun NL917FIB-2 User Manual

Page 26
1
3
2
RETRACTED
EXTENDED
STROKE
14.625
43.771
29.146
CYLINDER-14.625"/29.146 RETRACTED
ELBOW-1/4 NPT 90° 1/4 BARB
ELBOW-7/16-20 M/O-RNG/37*/.035 ORFICE
DESCRIPTION
15150
26667
C1514.3-0408N
PART NO.
3
2
1
ITEM
1
1
1
QTY.
30° ±10°
Exploded Views and Parts Lists
Hydraulic Cylinder Assembly - Main

Braun NL917FIB-2 Specifications

General

Brand	Braun
Model	NL917FIB-2
Category	Lifting Systems
Language	English
