Page 28
1
3
4
6
7
8
12
13
9
11
10
5
2
7
6
5
4
3
1 1 945-0618NA
QTY.ITEM PART NO.
HANDRAIL ASSY-NHTSA
DESCRIPTION
13
12
11
10
8
9
14
2
1
1
2
1
2
1
1
1
2
1
1
1
10027 BOLT-3/8-16 X 2" HEX HD. CAP
18657 RING-3/4 EXT SNAP/AUTO-BK
900-0413N PIN-PIVOT LOWER ARM
985-0606N SLIDE-PLATFORM ROTATE HANDRAIL
31677 SLIDE-UHMW-PLATFORM SLIDE-2X6.9"
11513 RIV-POP-SD64BS-3/16"-.13/.25/AUTO-BK
945-0640RNA ASSY-FOLD ARM-48 FTG-REAR
13617 NUT-3/8-16 UNC HEX LOCK/AUTO-BK
30227 WASHER-UHMW 0.75 OD X 0.39 ID X 0.25
29186 GAS SPRING-14.468 EXT/8.956 COM-P1=1150N
29185 BALL STUD-13MM W/ 3/8-16 FEMALE THREAD
12608 CLIP-SAFETY (GAS SPRING)
1 * 32519A SWITCH ASSEMBLY
* INDICATES ITEMS NOT SHOWN
Exploded Views and Parts Lists
Front Handrail Assembly
Rear Handrail Assembly
6
8
10
2
12
11
1
3
4
10
5
6
5
4
3
1
QTY.ITEM PART NO. DESCRIPTION
12
11
10
8
9
2
1
1
2
1
2
1
1
1
1
1
10027 BOLT-3/8-16 X 2" HEX HD. CAP
18657 RING-3/4 EXT SNAP/AUTO-BK
900-0413N PIN-PIVOT LOWER ARM
985-0606N SLIDE-PLATFORM ROTATE HANDRAIL
945-0640FNA ASSY-FOLD ARM-48 FTG-FRONT
13617 NUT-3/8-16 UNC HEX LOCK/AUTO-BK
30227 WASHER-UHMW 0.75 OD X 0.39 ID X 0.25
29186 GAS SPRING-14.468 EXT/8.956 COM-P1=1150N
29185 BALL STUD-13MM W/ 3/8-16 FEMALE THREAD
12608 CLIP-SAFETY (GAS SPRING)
1 945-0618NA HANDRAIL ASSY-NHTSA
7
13
7 1 31677 SLIDE-UHMW-PLATFORM SLIDE-2X6.9"
13 2 11513 RIV-POP-SD64BS-3/16"-.13/.25/AUTO-BK
