Page 25
Exploded Views and Parts Lists
Bottom Parallel Arm Assembly - Opposite Pump Side
Bottom Parallel Arm Assembly - Pump Side
1
2
3
DESCRIPTION
ARM-PARALLEL/BOTTOM-REAR (Incl. Items 2 & 3)
QTY.ITEM
1
PART NO.
945-0412NA1
2 BEARING-FLANGE-3/4" X 3/8"-12FDU064 24011
SHIM WASHER-.906"ID X 1.156"OD/.03"T/SS3 317714
1
2
3
5
4
SHIM WASHER-.906"ID X 1.156"OD/.03"T/SS317714
ARM-PARALLEL/BOTTOM-FRONT (Incl. Items 2 & 3)
BEARING-FLANGE-3/4" X 3/8"-12FDU06
ASSY-IB OCCUPIED4
3
2
ITEM
1
32514NA1
PART NO.
945-0458NKS
240114
QTY.
1
DESCRIPTION
NUT-#10-32 W/LOCKWASHER/AUTO-BK5 183492
To Next Page
