Page 27
1
5
2
4
3
84383
32734
31062A
945-0448FNW
PART N O.
31
21
11
QTY.ITEM
5
4
1
1
ROLLER-LIFT TITE
DESCRIPTION
ASSY-LIGHT-VERT. CHANNEL/PHILIPS SOCKET
WMT-VERTICAL CHANNEL-FRONT-48"
E CLIP-3/8 SHAFT
32408 RUBBER BUMPER-VERT CHAN.
NOTE:
NOTE:
DWG. NOTES
1) INSERT SOCKET OF LIGHT ASSY THRU TOP KEY
WHILE INSTALLING LIGHT. TIGHTEN SCREWS.
2) APPLY GREASE TO PIN PRIOR TO INSTALLING ROLLER.
1
2
Exploded Views and Parts Lists
Vertical Arm Assembly - Rear
Vertical Arm Assembly - Front
C
2
2
5
3
4
7
6
1
8
NOTE:
84383
32734
31062A
945-0448RNW
PART NO.
31
21
11
QTY.ITEM
5
4
1
1
ROLLER-LIFT TITE
DESCRIPTION
ASSY-LIGHT-VERT. CHANNEL/PHILIPS SOCKET
WMT-VERTICAL CHANNEL-REAR-48"
E CLIP-3/8 SHAFT
32408 RUBBER BUMPER-VERT CHAN.
DWG. NOTES
1) INSERT SOCKET OF LIGHT ASSY THRU TOP KEY
WHILE INSTALLING LIGHT. TIGHTEN SCREWS.
2) APPLY GREASE TO PIN PRIOR TO INSTALLING ROLLER.
3) HARNESS TO BE TUCKED INSIDE CHANNEL.
4) BUSHING NOT SHOWN.
NOTE:
61
72
32855A HARN-BRIDGE-NL/NCL-2
11481 SCREW-#4-40 X 3/8" RD. HD.
NOTE:
DETAIL A
(SCALE = 2X)
"A"
NOTE:
8 2 32949 WELD NUT-#4-40 X 1/8" BARREL-ZINC
1
2
3
4
