Breas Vivo 40 User Manual

25Product Description
Vivo 40 clinician’s manual
Doc. 003886 En-Us A-1e
3.4 The Vivo 40's Back and Side Panels
NO. ITEM FUNCTION
1 Air inlet Air path in, replaceable filters
2 Locking mechanism Release and lock the HA 01 humidifier or
rear lid
3 Air outlet Air path out to the patient
4 Memory card slot Read and write memory card
5 HA 01 humidifier Patient air humidification
6 AC power inlet Connection for an external AC power
source
7 On/Off AC power on and off
8 External DC inlet External DC power source connection
9 Data connection Data cable connection
(iCom/PC and the Vivo 40)
10 Internal battery Provides power for a limited time in case
of AC power disconnect
1
2
3
4
5
6
7
8
9
10

Breas Vivo 40 Specifications

General

Type	Non-invasive ventilator
Modes	CPAP
Humidifier	Optional, integrated heated humidifier
Power Supply	100-240V AC, 50/60Hz
Internal Battery	Yes, optional
Battery Life	Up to 8 hours
Alarms	Low battery
