PS1000/2000 User Instructions 17
P5 0-4 3 Baud rate for RS-232 0 = 1200 bps
1 = 2400 bps
2 = 4800 bps
3 = 9600 bps
4 = 19200 bps
p6 0-2 0 RS-232 protocol 0 = 8NO
1 = 7O1
2 = 7E1
p7 00-31 9 Scale resolution select Refer to Table 4.3 for resolution choices and
values.
P8 0-2 1 Calibration division size Refer to Table 4.4 and Table 4.5
0 = 1
1 = 2
2 = 5
p9 0-5 1 Decimal point in calibration Refer to Table 4.4 and Table 4.5
0 = 1
1 = 0.1
2 = 0.01
3 = 0.001
4 = 0.0001
5 = 10
p10 0,1 1 Calibration unit Refer to Table 4.4 and Table 4.5
0 = kg
1 = lb
p11 0-6 6 Weigh units enable 0 = only kg
1 = only lb
2 = only lb:oz
3 = kg or lb
4 = kg or lb:oz
5 = lb or lb:oz
6 = kg, lb, or lb:oz
p12 0-7 3 Power on zero range 0 = calibration zero -point +1%FS
1 = calibration zero -point +2%FS
2 = calibration zero-point +5%FS
3 = calibration zero-point +10%FS
4 = calibration zero-point +20%FS
5 = calibration zero-point +50%FS
6 = calibration zero-point +100%FS
7 = no limitation
p13 0-7 2
Zero range for [ZERO] key 0 = power-on zero-point +1%FS
1 = power-on zero-point +2FS
2 = power-on zero-point +5%FS
3 = power-on zero-point +10%FS
4 = power-on zero-point +20%FS
5 = power-on zero-point +50%FS
6 = power-on zero-point +100%FS
7 = no limitation
p14 0-2 2 Weight signal within power
on zero point range
0 = current weight
1 = calibration zero-point
2 = switch off zero point and power off tare
weight as current tare weight
SubMenu1 Option Default Parameter Description Comment
