User Configuration Settings
Parameter
Setting
Default settings in bold
P1.xy
Auto shut down timer (in minutes)
Set up time for the auto-off function.
(00 = 0ff, 01-15 = time in minutes)
P1.00
P1.01 – P1.15,
P1.5 = 5 minutes
P2.x
Hold and print key functionality
Setup button function
0 = Press button once to activate hold
1 = Press button once to print
2 = Press button to print / Press and hold button to activate hold.
P2.0 = Hold
P2.1 = Print
P2.2 = Print & Hold
P3.xy
Hold Function Settings
0 = No hold function active
1 = Averaging hold with manual push button release
The weight reading will be held on the display until a higher
weight is applied; this will automatically release the held weight
and re-hold it at the new higher weight reading.
2 = Averaging hold with automatic release and re-hold
s above but the weight reading will be held on the display until
the platform is emptied and the next weight reading over
10divisions is applied.
3-50 = Selectable hold window from +/- 3 to 50 divisions
Will hold the display reading once stable within a selectable
wei
ht ran
e. To release, the hold button must be repressed.
P3.0
P3.1
P3.2
P3.3 to 50
P4.x
RS232
Serial Interface
Settings for serial interface
0 = No RS232 output
1 = Print the displayed data once stable and when print key is
pressed
2 = Print gross, tare and net weight once stable and when print
key is pressed
3 = Continuously output gross weight
4 = Continuously output gross, tare and net weight
5 = Print the displayed data once stable, once only.
6 = Print gross, tare and net weight once stable, once only.
7 = Bidirectional - RS232, SBI protocol
P4.0
P4.1
P4.2
P4.3
P4.4
P4.5
P4.6
P4.7
P5.x
RS232 Baud Rate P5.0= 1200 P5.3= 9600
P5.1= 2400 P5.4= 19200
P5.2= 4800
P6.x
RS232 Data Format
0 = 8 bits, no parity, 1 start bit, 1 stop bit
1 = 7 bits, 1 even, 1 start bit , 1 stop bit
2 = 7 bits, 1 odd, 1 start bit, 1 stop bit
P6. 0
P6. 1
P6. 2
P7-P19 .x
SERVICE CONFIGURATIONS ONLY
Any adjustment to these settings could seriously affect the indicators performance.
Seek advice from a service engineer before changing.
