Brent 1082/882 — Parts
5-33
Please visit www.unverferth.com/parts/ for the most current parts listing.
ITEM DESCRIPTION PART NO. QTY NOTES
1
Hydraulic Cylinder, 3 x 24 - 3000 PSI 9004378 1
Fold Cylinder 3 x 24 Seal Kit 9004382 1
3 90° Elbow (9/16-18 JIC Male x 9/16-18 O-Ring Male) 9004379 2 w/.055 Restrictor
4 Hose 1/4 x 94 (9/16-18 JIC Female x 9/16-18 JIC Female) 9003275 1
5 Hose 1/4 x 75 (9/16-18 JIC Female x 9/16-18 JIC Female) 9003343 1
6 Adapter (9/16-18 JIC Male x 9/16-18 O-Ring Male) 9001495 3
7 90 ° Elbow (9/16-18 JIC Male x 9/16-18 O-Ring Male) 97445 1
8
Tee (9/16-18 JIC Male x 9/16-18 O-Ring Male
x 9/16-18 JIC Male)
9001710 1
9
Capscrew 5/16-18UNC x 1 3/4 9390-033 2 Grade 5
Lock Washer 5/16 9404-019 2
Hex Nut 5/16-18UNC 9394-004 2
10
Hose 1/4 x 238 (90° Elbow 9/16-18 JIC Female
x 3/4-16 O-Ring Male)
9003144 1
11 Hose 1/4 x 239 (9/16-18 JIC Female x 3/4-16 O-Ring Male) 9003210 1
12 Sleeve, Hose Marker (GREEN, Auger Lower) 9003998 1
13 Sleeve, Hose Marker (GREEN, Auger Raise) 9003997 1
14 Male Coupler 3/4-16 Female O-Ring 91383 6
15 Sleeve, Hose Marker (YELLOW, Spout In) 9004000 1
16 Sleeve, Hose Marker (YELLOW, Spout Out) 9003999 1
17
Hose 1/4 x 519 (90° Elbow 9/16-18 JIC Female
x 3/4-16 O-Ring Male)
9005302 1
18
Hose 1/4 x 525 (90° Elbow 9/16-18 JIC Female
x 3/4-16 O-Ring Male)
9005303 1
19 Adapter (9/16-18 JIC Female x 9/16-18 JIC Male) 95193 2 w/.030 Restrictor
20 Directional Spout Cylinder 1 1/2 x 8 Seal Kit 9005419 1
21 Flow Door Cylinder 2 1/2 x 36 Seal Kit 9005409 1
22 90° Elbow (9/16-18 JIC Female x 3/4-16 O-Ring Male) 9874 2
27 Hose 1/4 x 295 (9/16-18 JIC Female x 3/4-16 O-Ring Male) 9004121 2
28 Sleeve, Hose Marker (RED, Flow Door Open) 9003995 1
29 Sleeve, Hose Marker (RED, Flow Door Close) 9003996 1
30 Clamp Pair 9003816 6
31 Top Plate 9003814 6
32 Capscrew 5/16-18UNC x 1 1/4 9390-031 6 Grade 5
33 Pilot Operated Check Valve Block 9003990 1
34 Pin 1" Dia. x 3 1/2 (For Auger & Door Cylinders) 804572 3
35 Cotter Pin 3/16" Dia. x 2 9391-046 8
36 Pin 1" Dia. x 4 (For Rod Eye - Auger Cylinder) 250104 1
Hydraulics
(November 2015)
To Next Page
