Brent 1082/882 — Operation
3-13(October 2011)
U-Joint
Crank Holder
Crank Handle
Fig. 11
Weather Guard Tarp
Always use adequate caution when operating tarp.
If tarp is covered with snow/ice, remove snow/ice before operating.
End caps must be free from grain that may be piled on them. Grain should not be heaped
higher than end caps.
Tarp should be fully opened or completely closed during fi eld operation.
Procedure
1. Using both hands, carefully remove crank from holder.
2. Roll tarp to the desired location, choosing either a fully open or fully closed position.
3. To close the tarp, roll the main tarp tube clockwise up under the latch plate. Next, bring the crank
handle down perpendicular to the ground. Continue by lifting it up into the crank retainer.
4. Place crank in holder and re-insert retaining pin.
