brent 882 - Final Assembly

Brent 1082/882 — Parts
5-3
Please visit www.unverferth.com/parts/ for the most current parts listing.
Final Assembly
7B
Capscrew 1-8UNC x 8 9390-199 1 Grade 5
Lock Washer 1" 9404-041 1
Hex Nut 1-8UNC 9394-020 1
8 Capscrew/Large Flange 3/8-16UNC x 3/4 95585 6 Grade 5
9 Nut/Large Flange 3/8-16UNC 91263 6 Grade 5
10 Driveshaft Cover 280605B 1
11 Ladder Bracket Weldment 280603B 1
12 Platform Rubber Pad 9004114 1
13 Runner Pad 9001498 2
14 Ladder Weldment 280600B 1
15
Window 92403 2
Window Molding 250431 2
Bracket, Window Retainer 250461B 4
Capscrew 1/4-20UNC x 3/4 9390-003 8 Grade 5
Flat Washer 1/4 9405-064 8
Locknut 1/4-20UNC 9936 8
16 Transport Chain 9003278 1
17
Locknut 1-8UNC 92199 1
Capscrew 1-8UNC x 3 1/2 91299-189 1 Grade 8
18
Jack Assembly w/Pin 9004156 1
Pin 7/8" Dia. 9004171 -
19 Driveshaft Cover Plate 280554B
20 Trim Lock 9000787 A/R Specify in Feet
23 Rubber Grommet 9006780 3
24 Connector Holder 9001968 1
25
Capscrew 1/4-20UNC x 3/4 9390-003 2 Grade 5
Lock Washer 1/4 9404-017 2
Hex Nut 1/4-20UNC 9394-002 2
26 O-Ring 9005259 4
27 Storage Box 9005850 1
28 Capscrew 1/4-20UNC x 1 1/4 9390-006 2 Grade 5
29 Flat Washer 1/4" 9405-064 4
30 Fender Washer 94763 2
31 Locknut 1/4-20UNC 9936 2
PAINT SPRAY
Black 97013
Green 97015
Red 97301
Primer, Gray 9000592
Off White 97016
Touch-Up Paint
