Brent 1082/882 — Parts
5-6
Please visit www.unverferth.com/parts/ for the most current parts listing.
ITEM DESCRIPTION PART NO. QTY. NOTES
1 Compression Cell 9004909 2 Use Only With Scale
2 Bar, Spacer 280541 2
3 Bar, Axle Riser 280540 2 Used with Tracks Only
4 Rod Weldment-Retainer 280602 2
5 Cotter Pin 3/16x2 9391-046 4
6 Pin, 1x3 1/2 804572 2
7 Hex Nut, 1-8 UNC 9394-020 2
8 Shim, Axle 280396 A/R
9 Bushing, Self-Lubricating 9004690 2 2.37D x 2.017D x 1
10 Washer, Spacer 221530 8
11 Capscrew, 1/2-13 UNC x 3 1/2 9390-109 2
12 Locknut, 1/2-13 UNC 94981 2
13 Pin, Axle Pivot 280532 2
14 Spacer Bar 283856 2
15 Anti Rotate Bracket 283860 2
Axle Mounting (Wheels) — with 3 Point Scale
(November 2015)
