— 28 — "BRIG" inflatable boats
In order to install the sundeck (Fig. D11), perfom the next operations:
— open front seat (1) of the steering console;
— insert the sundeck floor boards (2) into the special hollows in the bow
locker and front part of the steering console base;
— close front seat (1) of the steering console;
— set the sundeck cushions (3) on the press-buttons.
HOW TO INSTALL SUNDECK.
D11
3
Always check fixing the sundeck
cushions.
2
1
1
2
