Eagle 6.7-2019 236G.01
— 19 —
FUEL SYSTEM.
Fuel system consists of the following components (Fig. D6):
— built-in fuel tank 191 L (4);
— external fuel fill (5);
— fuel line (from fuel fill to fuel tank) (1);
— fuel line (from fuel tank to engine) (3);
— electric fuel gauge (6);
— fuel drain line (2).
D6
Do not smoke when refueling. Stop the engine and switch off any electric equipments before refueling.
Check that there are no leaks in the fuel systems
Pre-filter and fuel valve must be installed by authorized representative specialists only.
Do not modify fuel system. Any modification, repair and planned maintenance of the fuel system may be made by
authorized representative specialists only.
1
3
6
2
5
4
