Eagle 6.7-2019 236G.01
— 33 —
80...350
Installed on a trailer (or on kell-blocks for storage) the boat should
been laying on all surface of the Main loading area (keel line) (see
Fig. T1).
It is possible to install the boat on several reference points. Thereby
the point of support (1) must be an obligatory, and the point of
support (2), (3), (4) must be an additional.
Lateral roller supports can be used only with a view of prevention
from tipping.
BOAT TRAILERING.
Fig.T1
Support areas
Main load area
(keel line)
Points of
support
Maximum transportable
mass – 1650 kg
In order to avoid the hull damage install the boat on the stated areas only.
4
3 2 1
1200+50
3200+50
4200+50
4
23
1
