Page #175 background imageLoading...
Page #175 background image
172
12
MODEL 310000 VERTICAL SERIES
ENGINE SPECIFICATIONS
Armature Air Gap .010 - .014 in. (.25 - .36 mm)
Crankshaft End Play .002 - .023 in. (.05 - .58 mm)
Spark Plug Gap .030 in. (.76 mm)
Valve Clearance – Intake .003 - .005 in. (.08 - .13 mm)
Valve Clearance – Exhaust .005 - .007 in. (.13 - .18 mm)
FASTENER TORQUE SPECIFICATIONS TORQUE
Air Cleaner Base 50 lb-in. (6 Nm)
Alternator 20 lb-in. (2 Nm)
Armature 30 lb-in. (3 Nm)
Blower Housings 90 lb-in. (10 Nm)
Blower Housing Brackets 90 lb-in. (10 Nm)
Breather 30 lb-in. (3 Nm)
Carburetor to Intake Manifold 70 lb-in. (8 Nm)
Carburetor Solenoid 40 lb-in. (5 Nm)
Connecting Rod 150 lb-in. (17 Nm)
Control Bracket 30 lb-in. (3 Nm)
Crankcase Sump 220 lb-in. (25 Nm)
Cylinder Head 220 lb-in. (25 Nm)
Cylinder Shield 40 lb-in. (5 Nm)
Exhaust Manifold / Adapter 165 lb-in. (19 Nm)
Flywheel Nut 100 lb-ft. (135 Nm)
Flywheel Fan 140 lb-in. (16 Nm)
Fuel Pump 90 lb-in. (10 Nm)
Governor Lever Nut 40 lb-in. (5 Nm)
Intake Manifold to Cylinder Head 90 lb-in. (10 Nm)
Muffler 90 lb-in. (10 Nm)
Oil Drain Plug – Side 100 lb-in. (11 Nm)
Oil Fill Tube 90 lb-in. (10 Nm)
Oil Pump Cover 90 lb-in. (10 Nm)
Regulator / Rectifier 40 lb-in. (5 Nm)
Rewind Starter 30 lb-in. (3 Nm)
Rocker Ball Set Screw or Nut 45 lb-in. (5 Nm)
Spark Plug 180 lb-in. (20 Nm)
Starter Motor 140 lb-in. (16 Nm)
Rocker Cover 60 lb-in. (7 Nm)
