Alternator Identification
The alternator systems installed on Briggs & Stratton OHV Engines can easily be identified by the color of
the stator output wires and the connector.
*Alternator output is determined by the size of the flywheel alternator magnets.
Alternator
Type
Stator
Output
Wire(s)
Color
Connector
Color
Al
ternator Output
(at 3600 RPM *)
* Unless Noted
Figure
#
DC Only Black White .5 Amp DC + Output at 2800
RPM
8
AC Only Black White 14 Volts AC (Lights)
Unregulated
9
DC Only Red Red 2-4 Amps + DC (Charging)
Unregulated
10
Dual
Circuit
Red
Black
White 2-4 Amps + DC (Charging)
Unregulated
14 Volts AC (Lights)
Unregulated
11
Tri-Circuit Black Green 5 Amps + DC (Charging)
5 Amps – DC (Lights)
12
Regulated
5 Amp
Black Green *1-5 Amps + DC (Charging)
Regulated
13
Regulated
9 Amp
Black Green *1-9 Amps + DC (Charging)
Regulated
13
