Features and Controls
Read the Operator’s Manual and safety rules before operating your electric pressure washer.
Compare the illustrations with your electric pressure washer to familiarize yourself with the locations of various controls and
adjustments. Save this original manual for future reference.
A - Spray Gun — Controls the application of water onto cleaning
surface with trigger device. Includes trigger lock.
B - 7-in-1 Nozzle — Contains seven different spray pattern
nozzles for various applications.
C - Accessory Tray — Provides convenient storage for standard
and optional accessories.
D - Nozzle Extension with Quick Connect — Allows you to
switch between 7-in-1 nozzle and optional accessories.
E - High Pressure Hose — Connect one end to high pressure
water outlet on hose reel and the other end to spray gun.
F - Warning Label — Identifies hazards to be avoided when
using your pressure washer.
G - Detergent Tanks — Use to hold up to one quart (0.95 l) of
pressure washer safe detergent in each tank.
H - Master ON/OFF Toggle Switch — Push top of switch in (I)
to turn pressure washer ON. Push bottom of switch in (0) to
turn pressure washer OFF.
J - Detergent Selector Switch — Allows you to select which
detergent tank you want to use.
K - Electric Cord with GFCI — The electric pressure washer and
operator is protected by a ground fault circuit interrupter
(GFCI).
L - Identification Label — Provides model and serial number of
pressure washer. Please have these readily available if calling
for assistance.
M - Water Supply Inlet — Connect to water supply using a 50 ft.
(15.24 m) maximum garden hose.
N - Hose Reel — Provides convenient storage for high pressure
hose.
A
F
G
J
K
M
N
B
C
E
D
H
L
